2026 Horizon HZ7 17.9K 83 in GN HOIST 16 ft / 3 ft
Get in Touch
Description
2026 Horizon HZ7 17.9K 83 in GN HOIST 16 ft / 3 ft
The HZ7 17.9K 83" Telescopic Dump Trailer offers unmatched durability and functionality. With GVWR of 17,900 lbs, an 8" I-Beam frame, telescopic hydraulic lift, and options for lengths (12', 14', 16') and side heights (2', 3', 4'), this trailer is engineered to handle tough jobs efficiently. Standard features include a Mega Toolbox, side steps, and DOT-approved LED lighting.
BUILT FOR RELIABILITY AND PERFORMANCE
DESIGNED FOR TOUGH JOBS
The HZ7 17.9K Dump Trailer is engineered for efficiency, boasting a 17,900 lbs GVWR and premium hydraulic hoist systems for seamless operation. Its robust design features a powder-coated finish, heavy-duty 8" I-Beam frame, and a durable 7-gauge steel bed. Optional side heights and lengths (12'-16') provide flexibility for any task. Take control of your hauling needs today!
CUSTOMIZE TO MATCH YOUR NEEDS
VERSATILITY MEETS DURABILITY
Whether you're hauling gravel or debris, the HZ7 17.9K Dump Trailer adapts to every job. Available in 12', 14', and 16' lengths with side heights up to 4', it ensures capacity for any load. Choose from vibrant color options and innovative features like hydraulic ramps and a manual tarp kit. Upgrade your efficiency now!
READY FOR YOUR HEAVIEST LOADS
MAXIMUM STRENGTH, MINIMUM EFFORT
Built to handle the toughest challenges, the HZ7 17.9K features dual 8K axles, a GVWR of 17,900 lbs, and a 39°-49° dump angle for optimized unloading. Equipped with an Interstate deep-cycle battery, KTI hydraulic pump, and premium Tecniq LED lighting, it's built for safety and efficiency. Invest in superior craftsmanship today!
Features May Include:
Highlights
- 8" I-Beam (15 lbs/ft)
- Mega Lockable Toolbox (Houses Battery and Pump)
- Robust Toolbox Latch
- 4 D-Rings Welded Inside Box
- Ramp Pockets w/ 6' 4" Long Slide In 4" Channel Ramps
- Weld On Spare Tire Mount
- Extra Marker Lights For Added Visibility
- Manual Tarp Kit
- Side Step On Both Sides
- Neckboss 10" Engineered I-Beam
Options:
Base Model
- HZ72GN122H-17.9KHZ7 GN 12' X 83" X 2' 17.9K Tandem Axle Hoist Dump Trailer
- HZ72GN142H-17.9KHZ7 GN 14' X 83" X 2' 17.9K Tandem Axle Hoist Dump Trailer
- HZ72GN162H-17.9KHZ7 GN 16' X 83" X 2' 17.9K Tandem Axle Hoist Dump Trailer
Tongue
- HZ7-10412k Ram 2 Speed Jacks
- HZ7-10612k Hydraulic Jacks
- HZ7-3026" Gn Riser Increase
- 503-007Shocker Hitch 2,5/16" Gn Coupler (30,000 lbs)
Chassis
- HZ7-612Fork Pockets
Dump
- HZ7-5193' High Sides
- HZ7-5204' High Sides
- 506-0138" Extensions Boards
- HZ7-5078" Integrated Wood Extension Brackets
- HZ7-40212" Crossmember Spacing
- HZ7-52642" Side Door (14' & 16' Dumps Only, Left Side)
- HZ7-217Storage - Box Located In Front Of Dump Box *Compatible With Wood Extension Option Only
- HZ7-505Pair Of Rear Stabilizer Stands
- HZ7-702Crank Over Tarp Kit
Lift System
- 509-005Tuff Wireless 2 Button Remote (Hoist or Telescopic)
- 509-017Tuff Wireless 2 Button Remote (Hoist - Hydraulic Jacks)
Running Gear
Tire upgrade options
- 501-0054 - ST235/75R17.5 18 Ply Tires Super Singles (6,005 lbs)
Spare tire options
- 501-104ST235/85R16 14 Ply Tire Single (4,400 lbs)
- 501-107ST235/75R17.5 18 Ply Tire Super Single (6,005 lbs)
Electrical and Lighting
- 505-00110 Watt Solar Panel
Finish
- HZ7-8032 - Tone Colors Chassis / Dump Box
- HZ7-80812ft-14ft Zinc Primer Undercoat
- HZ7-80616ft Zinc Primer Undercoat
Info
Industry
Trailer
Make
Horizon
Model
HZ7 17.9K 83 in GN HOIST
Trim
16 ft / 3 ft
Year
2026
MSRP
N/A
Category
Dump Trailer
Subcategory
Dump Trailer
Specs
Length
16 ft | Tongue: 94 in Long (From Behind Riser)
Height
Side: 3 ft | Bed: 28 in | Tongue: 70 in High (From Underneath Neck)
GVWR
17,900 lbs | GAWR: 8,000 lbs
Width
Bed: 83 in
Frame
3 in x 5 in x 1/4 in Angle Iron | Main: 8 in I-Beam (15 lbs/ft) | Wiring: Double Insulated Wiring Harness
Fenders
12 ga. Diamond Plate Steel Fenders
Suspension
Spring | Axle: 8k Electric Brake Auto Adjust Oil Bath Spring Axles
Tires
Radial Tires | Size: ST235/85R16
Coupler
Standard: Adjustable 2-5/16 in GN Coupler (30,000 lbs)
Gate/Door
3 Way Door - Spreader Gate
Crossmembers
3 in Channel (3.50 lbs/ft) 16 in Spacing
D-Rings
4 D-Rings Welded Inside Box
Wheels
Rims: 16 in Black Mod Wheels
Safety Chains
3/8 in Grade 70 Safety Chain w/Clevis Hook (2 each) | Tarp: Manual Tarp Kit | System: 2 Button Hydraulic - Power Up / Power Down | Reflective: 3M Dot Compliant Reflective Tape
Tongue
Neckboss 10 in Engineered I-Beam | Spare: Weld On Spare Tire Mount
Pump
KTI 12V Hydraulic Pump
Finish
Paint type: Powdercoat | Prep: Steel Grit Blasted | Colors: Military Green, Desert Tan, Flame Orange, Midnight Black, Spectra Yellow, Blue Horizon, Lime Green, Ash Grey, True Red, Pearl White, Cloud Grey, Navy Blue, Sunset Orange | Style: 2 Tone Colors Available, Chassis / Dump
Top Rail
3 in x 5 in x 11 ga. Tubing | Width: 83 in
Ramps
Ramp Pockets w/ 6 ft 4 in Long Slide In 4 in Channel Ramps (7,000 LBS WHEEL RATING EACH ONLY OVER AREA OF 12 in OR MORE)
Battery
1 - Interstate 27 Deep Cycle Battery
Cylinder
Lift: Hoist w/ 5 in x 16 in Single Push Cylinder (15,000 lbs)
Notes
Front Jack: 2 Side Wind Spring Loaded Drop Jack Legs (12,000 lbs) | Toolbox: Mega Lockable Toolbox Houses Battery & Pump (w/ Extra Storage) | Dump Angle: 39° - 49° | Stake Pockets: 1,5/8 in x 3,5/8 in (ID) Stake Pockets
Floor
7 ga. Steel Bed
Lights
DOT Approved Tecniq LED Lights
Controller
14 ft Control Cable
Step
Side Step On Both Sides
Warranty
Axle: 5 Year Spring Axle Warranty | Trailer: 3 Year Frame / 1 Year Parts Warranty
