2026 Horizon HET 22.4K 82 in GN 26 ft
Get in Touch
Description
2026 Horizon HET 22.4K 82 in GN 26 ft
Discover the HET 22.4K 82" Gravity Tilt Deck, a premium gooseneck equipment trailer built for durability and efficiency. Featuring a 22,400 lbs GVWR, 82" wide deck, 16' tilt deck with automatic lowering, and advanced features like a Mega Lockable Toolbox and 11-Year Axle Warranty, this trailer is engineered for superior performance and reliability.
The HET Gooseneck Heavy Duty Equipment Tilt Trailer delivers exceptional strength and professional-grade performance, offering a rugged 22,400 lb GVWR. It features a heavy-duty 10" I-beam frame, 10K Super Single torsion axles, and a 16' gravity tilt deck with a 15° tilt angle. Its 3/16" diamond plate deck, reinforced rub rail, and stake pockets ensure durability. Equipped with a mega toolbox, DOT LED lighting, and a winch-ready neck, it’s built for demanding hauling.
BUILT FOR PERFORMANCE
ULTIMATE DURABILITY FOR HEAVY LOADS
The HET 22.4K 82" Gravity Tilt Deck redefines strength with its 10" I-Beam frame and advanced Neckboss engineering. Designed with 22,400 lbs GVWR and 16' tilt deck, it ensures reliable performance for the toughest jobs. Equipped with a Mega Lockable Toolbox, removable fenders, and 11-Year Axle Warranty, this gooseneck trailer delivers power and peace of mind.
EFFICIENCY MEETS INNOVATION
SMOOTH LOADING, EVERY TIME
Experience effortless loading with the HET 22.4K's automatic lowering tilt deck and robust 3" x 16" hydraulic cylinder system. Its 82" deck width and pine lumber flooring enhance usability, while diamond plate fenders provide added durability. Maximize safety and functionality with Tecniq LED lights, adjustable GN coupler, and Grade 70 safety chains.
EXCEPTIONAL CAPACITY & STYLE
BUILT FOR DEMANDING JOBS
Available in lengths up to 26', the HET 22.4K blends strength and style. Choose from vibrant powder-coated colors like Flame Orange and Military Green. With a GAWR of 10,000 lbs per axle, radial tires, and torsion suspension, this trailer handles heavy equipment with ease while ensuring a sleek, professional appearance on every job.
Features may include
Highlights
- 10" I-Beam (17 lbs/ft)
- Neckboss 10" Engineered I-Beam
- Mega Lockable Toolbox
- Robust Toolbox Latch
- Weld On Spare Tire Mount
- Outer Deck Frame 3/16" Diamond Plate
- 16' Tilt Deck
- 2 D-Rings In Between Fenders
- 2" x 6" x 7ga. Tubing Bed Frame (Tilt)
- 82" Wide In Between Fenders
- Storage Box Behind Neck / Winch Ready
- Removable Fenders
Options
Base Model
- HET2GN2082-22.4KHET GN 20' x 82" 22.4K Tandem Axle Gravity Tilt Deck Trailer
- HET2GN2282-22.4KHET GN 22' x 82" 22.4K Tandem Axle Gravity Tilt Deck Trailer
- HET2GN2482-22.4KHET GN 24' x 82" 22.4K Tandem Axle Gravity Tilt Deck Trailer
- HET2GN2682-22.4KHET GN 26' x 82" 22.4K Tandem Axle Gravity Tilt Deck Trailer
Tongue
- HET-10412k Ram 2 Speed Jacks$273.00 (USD)
- HET-10612k Hydraulic Jacks$2,665.00 (USD)
- HET-3026" Gn Riser Increase$149.50 (USD)
- 503-007Shocker Hitch 2,5/16" Gn Coupler (30,000 lbs)$1,638.00 (USD)
Deck
- HET-40212" Crossmember Spacing$15.60 (USD) per linear ft
- 506-005Full Deck Blackwood "Classic" Rubber Infused Lumber$37.70 (USD) per linear ft
- HET-42012ga. Diamond Plate Steel Deck$54.60 (USD) per linear ft
- 508-0014 Additional D-Rings Welded Across Deck (1/2" - 4,000 lbs)$84.50 (USD)
- 508-0026 Additional D-Rings Welded Across Deck (1/2" - 4,000 lbs)$123.50 (USD)
- 508-0038 Additional D-Rings Welded Across Deck (1/2" - 4,000 lbs)$162.50 (USD)
- 508-0094 - Latch On Tie Down Fittings 2" O-ring (4,000 lbs)$54.60 (USD)
- 508-0106 - Latch On Tie Down Fittings 2" O-ring (4,000 lbs)$84.50 (USD)
Lift System
- Lift system
- 509-016Tuff Wireless 2 Button Remote (Hydraulic Jacks)$708.50 (USD)
- 509-018Tuff Wireless 4 Button Remote (Hydraulic Jacks - Winch)$858.00 (USD)
- Winch add on( installed in storage box on neck)
- 504-01213.5k Steel Cable Winchmax Winch$1,774.50 (USD)
- 504-01313.5k Synthetic Rope Winchmax Winch$2,047.50 (USD)
- 504-01417.5k Steel Cable Winchmax Winch$2,255.50 (USD)
- 504-01517.5k Synthetic Rope Winchmax Winch$2,938.00 (USD)
Running Gear
- Spare tire options
- 501-107ST235/75R17.5 18 Ply Tire Super Single (6,005 lbs)$318.50 (USD)
Electrical and Lighting
- 505-00110 Watt Solar Panel$481.00 (USD)
- HET-3052 - Cargo Lights Mounted On Riser$546.00 (USD)
Finish
- HET-81520ft & Up Zinc Primer Undercoat$1,365.00 (USD)
- HET-802Fenders Painted Black$409.50 (USD)
Info
Industry
Trailer
Make
Horizon
Model
HET 22.4K 82 in GN
Trim
26 ft
Year
2026
MSRP
N/A
Category
Equipment Trailer
Subcategory
Equipment Trailer
Specs
Length
26 ft | Tilt Deck: 16 ft
Width
Deck: 82 in | Width Between Fenders: 82 in
Height
Deck: 22 in
Axles
2 Axles: | 10k Lippert Electric Brake Auto Adjust S/Single Oil Bath Torsion Axles 8 On 6.5 in
GVWR
22,400 lbs | GAWR: 10,000 lbs
Finish
Paint Type: Powdercoat | Prep: Steel Grit Blasted | Color: Military Green, Desert Tan, Flame Orange, Midnight Black, Spectra Yellow, Blue Horizon, Lime Green, Ash Grey, True Red, Pearl White, Cloud Grey, Navy Blue, Sunset Orange
Warranty
Axle: 11 Year Lippert Torsion Axle Warranty | Trailer: Three (3) Year Frame One (1) Year Parts Warranty
Tongue
Type: Neckboss 10 in Engineered I-Beam | Length: 60 in | Spare: Weld On Spare Tire Mount | Winch Plate: Winch Plate Behind Neck
Coupler
Adjustable Auto Latch 2-5/16 in Bp Coupler (21,000 lbs)
Notes
Safety: 3M Dot Compliant Reflective Tape | Tilt Angle: 15° | Tie Down Slots 82 in Wide Deck: Slots for Latch On Tie Down Fittings Front End Of Deck | Toolbox: Mega Lockable Toolbox | Jack: 1 Side Wind Spring Loaded Drop Jack Leg (12,000 lbs)
Safety Chains
3/8 in Grade 70 Safety Chain w/Clevis Hook (2 each)
Frame
10 in I-Beam (17 lbs/ft) | Deck Frame 102 in Wide Deck: 3/16 in Diamond Plate | Tilt Deck Frame: 2 in x 6 in x 7ga. Tubing Bed Frame
Floor
Pine Lumber Floor
Crossmembers
3 in Channel (3.50 lbs/ft) 16 in Spacing
D-Rings
Weld On D-Rings: 2 - D-Rings In Between Fenders | Bolt On Swivel D-Rings: 2 - Flush Mount Galvanized Swivel D-Rings Front Of Trailer
Top Rail
Rub Rail: 2 in x 3/8 in Rub Rail | Stake Pockets: 1,5/8 in x 3,5/8 in (ID) Stake Pockets (Spaced At 24 in) | Spools: 2 in x 10ga. Pipe Spools (Spaced At 24 in)
Fenders
Fenders 82 in Wide Deck: 12ga. Removable Diamond Plate Steel Fenders
Cylinder
1 - 3 in x 16 in Cylinder | System: Gravity Up / Down | Tank: Large Reservoir | Valve: 3 Way Valve Control
Tires
ST235/75R17.5, Super Single 18PR 6005 lbs
Wheels
17.5 in Black Mod Wheels
Suspension
Torsion
Battery
Breakaway System: 2382 Brightway Group Electric Breakaway Kit | Wiring Harness: All-Weather Wiring Harness (7-Way RV) | Frame Wiring: Double Insulated Wiring Harness
Lights
DOT Approved Tecniq LED Lights
